2.5G SFP BIDI TX1490/RX1550NM 80KM DDM
- 型号 : GS-4845BL-80
- 2.5G SFP BIDI TX1490/RX1550NM 80KM DDM
-
The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 2.488Gbps/2.125Gbps and 80km transmission distance with SMF.
The transceiver consists of three sections: a DFB laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
- Dual data-rate of 2.488Gbps/2.125Gbps operation
- 1490nm DFB laser and APD photodetector for 80km transmission
- Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
- Digital Diagnostic Monitoring:
- Internal Calibration or External Calibration
- Compatible with RoHS
- +3.3V single power supply
- Operating case temperature:
- Standard : 0 to +70°C
| Package (Form Factor) | BIDI SFP |
| Data Rate (typical) | 2.488 Gb/s |
| Centre Wavelength | Tx1490nm/Rx1550nm |
| Distance | 80km |
| Diagnostics | Digital Monitor |
| Transmitter | DFB Laser |
| Receiver | APD photo detector |
| TX Output Power (dBm) | 0~+5 |
| RX Sensitivity (dBm) | -28 |
| Low/High Case Temperature | 0°C~70°C |
| Voltage Supply (typical) | 3.3v |
| Connector | Simplex LC/UPC |
- SDH STM-16 and SONET OC-48 system
- Fiber Channel
- Switch to Switch interface
- Switched backplane applications
- Router/Server interface
- Other optical transmission systems
